GUIDE SPECIFICATION  |  Section 4.3
                                                                              POLYCOAT-AQUASEAL  5000
                                                                                                            ™
                                                                                             Single Component, Bitumen
                                                                               Modified Waterproofing Membrane Product
                                                                                Approved by City of Los Angeles RR#25935


            Product Description                                   Features
            Polycoat-Aquaseal   5000 is a single component, liquid applied,
                           ™
            bitumen modified, coal tar free, moisture cured polyurethane   •  Economical
            waterproofing membrane. The standard Polycoat-Aquaseal    •  User Friendly
                                                              ™
            5000 may be applied to both fully cured concrete (28 days for
            poured in place and 10 days after grouting for block). Polycoat-  •  Labor Saving
            Aquaseal  5000GC may be applied to Green Concrete. For   •  Meets the Criteria of ASTM C836 and E96
                    ™
            Green Concrete, GC Additive must be added to Polycoat-
            Aquaseal  5000 at a ratio of ½ pint GC Additive (256 ml) to 5   •  Resistant to Bacteria
                    ™
            gallons (18.9 liters) of Polycoat-Aquaseal  5000. Thoroughly   •  User Friendly
                                              ™
            mix with a variable speed drill and mixing paddle at slow
            speed.                                                Typical Uses
            It is available in four application versions. For 28-day cured   •  Basements    •  Planters
            concrete Horizontal (H) and Vertical (V) grade versions should
            be used. For Green Concrete (GC) Horizontal (GCH) and Vertical   •  Between Slabs   •  Shower Pans
            (GCV) grade versions are used. Polycoat-Aquaseal   5000 has
                                                      ™
            VOC levels equal to or less than 100 grams per liter. Make   •  Bridges          •  Tunnels
            sure to use the correct grade of product which complies with
            VOC regulations/requirements applicable as per federal, state,
            statutory, counties, cities and local bodies at the place of   PACKAGING
            installation.
            Color                                                  5-Gallon         5 gallon (18.9 liter) pail
            Black
                                                                   55-Gallon        55 gallon drum, net fill 50 gallons (189
            Coverage                                                                liters)
            The approximate coverage is 2 gallons/100 per sqft (0.41l/
            sqft) or 100 sqft/gallon which results in a dry film thickness of   recommended primer.
            28 mils (355 microns). Coverage rate will depend on surface
            roughness and porosity.                              Mixing
                                                                 Before application, Polycoat-Aquaseal  5000 should be
                                                                                                    ™
            Surface Preparation                                  thoroughly mixed using a mechanical mixer at slow speed
            Refer to General Guidelines for complete information.  to ensure a homogeneous material. Take care not to allow
            Joints, Cracks and Flashing:                         entrapment of air into the material. Do not mix in an up and
                                                                 down motion.
            Apply a stripe coat of Polycoat-Aquaseal  5000 over all cracks
                                             ™
            up to 1/16” (1.58 mm) width. All cracks over 1/16” (1.58 mm)  Application
                                                                                  ™
            width must be caulked with a polyurethane sealant.   Polycoat-Aquaseal  5000 may be applied with a brush,
                                                                 squeegee, trowel, roller or airless sprayer. Over smooth
            All metal flashings must be primed with manufacturer’s   surfaces, such as poured-in-place concrete, apply Polycoat-
                                                            ™
             Technical Data (Based on Draw Down Film) Polycoat-Aquaseal  5000 (100 VOC) Properties
                                                     5000H            5000V            5000GCH          5000GCV
                                                  HORIZONTAL         VERTICAL        HORIZONTAL         VERTICAL
             Hardness, ASTM D2240                    50 ± 5 Shore A    45 ± 5 Shore A   50 ± 5 Shore A    45 ± 5 Shore A
             Tear Resistance, Die C, ASTM D624          70 ± 20 pli      100 ± 20 pli      70 ± 20 pli      100 ± 20 pli
                                                     9.3 ± 2.6 kN/m    13.3 ± 2 kN/m    9.3 ± 2.6 kN/m    13.3 ± 2 kN/m
             Tensile Strength, ASTM D412               450 ± 50 psi     500 ± 50 psi      450 ± 50 psi     500 ± 50 psi
                                                      3.1 ± 0.3 MPa    3.4 ± 0.3 MPa     3.1 ± 0.3 MPa     3.4 ± 0.3 MPa
             Ultimate Elongation, ASTM D412             500 ± 50%        500 ± 50%         450 ± 50%         450 ± 50%
             Specific Gravity                            1.28 ± 0.1       1.20 ± 0.3        1.28 ± 0.1       1.20 ± 0.1
             Total Solids by Weight, ASTM D2369          95 ± 3%           91 ± 3%           95 ± 3%          91 ± 3%
             Total Solids by Volume, ASTM D2697          94 ± 3%           89 ± 3%           94 ± 3%          89 ± 3%
             Viscosity at 80°F (27°C)               5000 ± 2000 cps  40,000 ± 20,000 cps  5000 ± 2000 cps  40,000 ± 2000 cps
             Volatile Organic Compounds, ASTM D-2369-81  0.83 lb/gal,    0.83 lb/gal,      0.83 lb/gal,     0.83 lb/gal,
                                                       100 gm/liter     100 gm/liter      100 gm/liter     100 gm/liter
             Service Temperature                     -25°F to 200°F    -25°F to 200°F    -25°F to 200°F   -25°F to 200°F
                                                     -31.7°C to 65°C   -31.7°C to 65°C  -31.7°C to 65°C   -31.7°C to 65°C
