GUIDE SPECIFICATIONS | Section 4.1
®
POLYCOAT PC-IM 129 SYSTEM

Description:
The Polycoat PC-IM 129 System is a two component, Technical Data
®
liquid applied, asphalt extended aromatic polyurethane
waterproofing membrane system. The system utilizes two Aromatic Polyurethane 58 Dry Mils, (1473 microns)
coats of Polycoat PC-IM 129 with an optional polyester inner- Waterproof Membrane NSF 61 Approved for Portable
®
ply mat. This system adheres to asphalt, concrete, wood and Water
metal substrates. It is durable and will provide trouble free
waterproofing. It is an elastomeric system designed to expand Primer Polyprime 2180SC
®
®
and contract with normal structural movements. The Polycoat ® Polyprime U
®
PC-IM 129 waterproofing system has a watertight monolithic Polyprime EBF-LV
surface. This system has a wide range of uses and is ANSI /
NSF 61 approved for contact with Potable Water. Make sure Topcoat Polycoat® PC-IM 129
to use the correct grade of product which complies with VOC
regulations/requirements applicable as per federal, state,
statutory, counties, cities and local bodies at the place of Packaging
installation.
Polyprime 2180SC, 2-gallon kit: One 1 gallon
®
Features Typical Usage Polyprime U and (3.78 liters) can of Side-A
®
®
• ANSI / NSF 61 • Containment Polyprime EBF-LV and One 1 gallon (3.78 liters)
can of Side-B
Approved • Pond Liner 10-gallon kit: One 5 gallon
• Bridges Cracks and • Potable Water (18.9 liters) pail of Side-A
Joints Containment and One 5 gallon (18.9 liters)
• Economical • Reservoirs (with scrim) pail of Side-B
• Impervious To • Tank Liner
®
Water and Aqueous • Waterproofing Roofing Polycoat PC-IM 129 4.5-gallon kit (17 liters): One
Chemicals (with scrim) 1/2 gallon jar, net fill 0.45
gallon (1.70 liters) of Side-A
• Low VOC and One 5 gallon
• Seamless pail, net fill 4.05 gallon
(15.30 liters) of Side-B
Common Substrates
• Asphalt • Concrete Application
ASPHALT/CONCRETE/STEEL/METAL
• Metal • Steel
PHASE 1:
• Wood Check area of application to ensure that it conforms to the
Primers, base and topcoats have a shelf life of 1 year from date substrate requirements, as stated in the General Guidelines
of manufacture in original, factory-sealed containers when stored section. Prime all joints, cracks, flashings with approved
indoors at a temperature between 60-95˚F (15-35˚C).
primers as specified below in Phase 2. Apply PC-260 over all
joints, cracks and flashing. Bridge joints, cracks, and flashings
with 4” (10/16 cm) Straight Jacket Tape pushing it into the
PC-260 with a trowel. Using PC-260 as a caulking compound
Product Instructions will shorten the curing time appreciably over conventional
For complete information associated with the application of polyurethane caulks. Over reinforcement tape, apply a stripe
all Polycoat Products decking systems and products, refer coat of PC-260 and taper it onto the adjacent surface. Allow
to the General Guidelines and Technical Data Sheets of the the surface to cure for 1 to 2 hours.
Polycoat Products catalog, which describes the products,
surface preparation, job conditions, finishing details and other Cracks in asphalt/concrete over 1/8” (0.125 cm) must be filled
necessary information. with PC-260. Place scrim over crack and apply 10-20 mils
(2.54-5.08 cm). Allow to cure 2 to 4 hours.

Note: The concrete substrate must be primed with Polyprime 21 in
®
submerged conditions.

POLYCOAT PRODUCTS TEL 562.802.8834 | FAX 562.921.7363 Section 4.1
