GUIDE SPECIFICATIONS  |  Section 3.1
                                                                                            POLY-I-GARD  246
                                                                                                             ™







                                                                   Technical Data

                                                                   40 Dry Mils (1016 microns)
                                                                   ICC-ES Evaluated
                                                                   Class A Fire Rated on Concrete
                                                                   Vehicular Traffic Deck Coating System

                                                                   Primer             Polyprime  2180/2180SC
                                                                                              ®
                                                                                              ®
                                                                                      Polyprime  21
                                                                   Intermediate Coat  Poly-I-Gard  246
                                                                                               ™
                                                                   Topcoat            Poly-I-Gard  246
                                                                                               ™


                                                                   Packaging

              Concrete Substrate (properly prepared substrate)     Polyprime  2180/2180SC   2-gallon kit: One 1 gallon
                                                                            ®
                                                                                            (3.78 liters) can of Side-A
                                                                                            and One 1 gallon (3.78 liters)
             Features                 Typical Usage                                         can of Side-B.
                                                                                            10-gallon kit: One 5 gallon
              •  Chemical Resistance    •  Balconies                                        (18.9 liters) pail of Side-A
              •  Elastomeric            •  Concrete Roof and Decks                          and One 5 gallon (18.9 liters)
              •  Recoatable               Over Occupied Spaces                              pail of Side-B
              •  Seamless               •  Helicopter Pads
              •  Waterproof             •  Vehicular Decks         Polyprime  21            3-gallon kit: One 3.5 gallon
                                                                            ®
                                        •  Walkways/Stairs                                  pail, net fill 2 gallons (7.57
                                                                                            liters) of Side-A and One
                                                                                            1 gallon (3.78 liter) can of
                                                                                            Side-B or
             Primers, base and topcoats have a shelf life of 1 year from date               15-gallon kit: Two 5 gallon
             of manufacture in original, factory-sealed containers when stored              (18.9 liter) pails of Side-A
             indoors at a temperature between 60-95˚F (15-35˚C).                            and One 5 gallon (18.9 liter)
                                                                                            pail of Side-B
            Description
            The Poly-I-Gard  246 Vehicular Traffic Deck System is a liquid   PC-440/440SC/440SF  1 gallon (3.78 liters) can or 5
                         ™
            applied, high solids, moisture-cured waterproofing system.                      gallon (18.9 liters) pail
            It utilizes an epoxy primer and one easy-to-use high tensile,
                                                                            ™
            aromatic polyurethane to complete the system. The system   Poly-I-Gard  246     5 gallon pail (18.9 liters) with
            is a user-friendly application that is specifically designed to                 1/2 pint (0.245 liters) can of
                                                                                            catalyst or 55 gallon drum
            be tough and durable enough to withstand vehicular traffic.                     net 50 gallons (189 liters)
            It is an elastomeric system designed to expand and contract                     with two 1/2 quart cans of
            with normal structural movements. The three coat application                    catalyst (0.472 liters)
            saves time and labor. The system can be applied to protect
            surfaces against spalling, freeze/thaw damage, and chemicals   Approvals, Codes & Testing
            commonly encountered on vehicular traffic decks. It will   •  Class A Fire Rating on Concrete, UBC Standard 32-7, ASTM
            neither soften in heat nor embrittle in the cold. Installed and   E108, UL 790, NFPA 256
            maintained properly, the Poly-I-Gard  246 Vehicular Traffic   •  ICC-ES Report ESR-2785
                                            ™
            Deck System will ensure years of service. Make sure to use the   •  Los Angeles City General Approval Report #RR25171
            correct grade of product which complies with VOC regulations/  •  Meets the Criteria of ASTM C957
            requirements applicable as per federal, state, statutory,   •  Meets the Criteria of ASTM C1028 Co-efficient of Friction
            counties, cities and local bodies at the place of installation.
