GUIDE SPECIFICATIONS  |  Section 3.2
                                                                                         POLY-I-GARD  246SC
                                                                                                          ™







                                                                   Technical Data

                                                                   40 Dry Mils
                                                                   Vehicular Traffic Deck Coating System


                                                                   Primer             Polyprime  EBF-LV
                                                                                              ®

                                                                   Intermediate Coat  Poly-I-Gard  246SC
                                                                                               ™
                                                                   Topcoat            Poly-I-Gard  246SC
                                                                                               ™



                                                                   Packaging

                                                                   Polyprime  EBF-LV         2-gallon kit: One 1 gallon
                                                                            ®
              Concrete Substrate (properly prepared substrate)                               (3.78 liters) can of Side-A
                                                                                             and One 1 gallon (3.78 liters)
                                                                                             can of Side-B or
             Features                 Typical Usage                                          10-gallon kit: One 5 gallon
                                                                                             (18.9 liters) pail of Side-A
              •  Chemical Resistance    •  Vehicular Decks                                   and One 5 gallon (18.9 liters)
              •  Elastomeric            •  Walkways/Stairs                                   pail of Side-B
              •  Recoatable             •  Balconies
              •  Seamless               •  Helicopter Pads         Poly-I-Gard  246SC        5 gallon pail (18.9 liters) with
                                                                            ™
              •  Waterproof             •  Concrete Roof and Decks                           1/2 pint (0.245 liters) can of
                                          Over Occupied Spaces                               catalyst or
                                                                                             55 gallon drum net 50
                                                                                             gallons (189 liters) with two
             Primers, base and topcoats have a shelf life of 1 year from date                1/2 quart cans of catalyst
             of manufacture in original, factory-sealed containers when stored               (0.472 liters)
             indoors at a temperature between 60-95˚F (15-35˚C).
                                                                 Approvals, Codes & Testing
            Description                                            •  Will comply with Class A Fire Rating on Concrete, UBC
            The Poly-I-Gard  246SC  Vehicular Traffic Deck System is a   Standard 32-7, ASTM E108, UL 790, NFPA 256
                         ™
            liquid applied, high solids, moisture-cured waterproofing   •  Meets the Criteria of ASTM C1028 Co-efficient of Friction
            system. It utilizes an epoxy primer and one easy-to-use high
            tensile, aromatic polyurethane to complete the system.  Product Instructions
            The system is a user-friendly application that is specifically   For complete information associated with the application of
            designed to be tough and durable enough to withstand   all Polycoat Products decking systems and products, refer
            vehicular traffic. It is an elastomeric system designed to   to the General Guidelines and Technical Data Sheets of the
            expand and contract with normal structural movements. The   Polycoat Products catalog, which describes the products,
            three coat application saves time and labor. It can be applied   surface preparation, job conditions, finishing details and other
            to protect surfaces against spalling, freeze/thaw damage,   necessary information.
            and chemicals commonly encountered on vehicular traffic
            decks. It will neither soften in heat nor embrittle in the cold.  Coatings Application
            Make sure to use the correct grade of product which complies   PHASE 1:
            with VOC regulations/requirements applicable as per federal,   Check area of application to ensure that it conforms to the
            state, statutory, counties, cities and local bodies at the place   substrate requirements, as stated in the General Guidelines.
            of installation.                                     Prime all joints, cracks, flashings with approved primers as




        POLYCOAT PRODUCTS TEL 562.802.8834  |  FAX 562.921.7363                                           Section 3.2
        wpsales@polycoatusa.com  |  www.polycoatusa.com
