GUIDE SPECIFICATIONS  |  Section 3.3
                                                                                   POLY-I-GARD  295/295OF
                                                                                                    ™







                                                                   Technical Data

                                                                   61 Dry Mils (1549 microns)
                                                                   Vehicular Traffic Deck Coating System


                                                                   Primer             Polyprime  EBF-LV
                                                                                              ®
                                                                                      Polyprime  2180SC
                                                                                              ®
                                                                   Intermediate Coat  Poly-I-Gard  295/295OF
                                                                                               ™
                                                                   Topcoat            Poly-I-Gard  295/295OF
                                                                                               ™





                                                                   Packaging
              Concrete Substrate (properly prepared substrate)
                                                                   Polyprime  EBF-LV         2-gallon kit: One 1 gallon
                                                                            ®
                                                                   or                        (3.78 liters) can of Side-A
             Features                 Typical Usage                Polyprime  2180SC         and One 1 gallon (3.78 liters)
                                                                            ®
                                                                                             can of Side-B or
              •  Chemical Resistance    •  Balconies                                         10-gallon kit: One 5 gallon
              •  Elastomeric            •  Concrete Roof and Decks                           (18.9 liters) pail of Side-A
              •  Recoatable               Over Occupied Spaces                               and One 5 gallon (18.9 liters)
              •  Seamless               •  Helicopter Pads                                   pail of Side-B
              •  UV Stable              •  Vehicular Decks
                                                                             ™
              •  Waterproof             •  Walkways/Stairs         Poly-I-Gard  295/295OF    4.4 gal kits: One 5 gallon
                                                                                             pail, net 4 gallons (15.12
                                                                                             liters) of Side-A & one 1/2
                                                                                             gallon jar, net 0.4 gallons
                                                                                             (1.512 liters) of Side-B
             Primers, base and topcoats have a shelf life of 1 year from date
             of manufacture in original, factory-sealed containers when stored
             indoors at a temperature between 60-95˚F (15-35˚C).

            Description                                          complies with VOC regulations/requirements applicable as
            Poly-I-Gard  295/295OF Vehicular Traffic Deck System is an   per federal, state, statutory, counties, cities and local bodies
                     ™
            odor friendly, two-component, rapid setting, liquid applied,   at the place of installation.
            high solids, chemically-cured waterproofing system. The   Product Instructions
            system utilizes an epoxy primer and one easy to use high   For complete information associated with the application of
            tensile, solvent free, hybrid aliphatic polyurea to complete   all Polycoat Products decking systems and products, refer
            the system. The system is a user-friendly application of a   to the General Guidelines and Technical Data Sheets of the
            low odor coating that is specifically designed to be tough   Polycoat Products catalog, which describes the products,
            and durable enough to withstand vehicular traffic. It is an   surface preparation, job conditions, finishing details and other
            elastomeric system designed to expand and contract with   necessary information.
            normal structural movements. The three coat application saves
            time and labor. It can be applied up to 1.5 gal/100sqft or 66  Coatings Application
            sqft/gallon to protect surfaces against spalling, freeze/thaw   PHASE 1:
            damage, and chemicals commonly encountered on vehicular   Check area of application to ensure that it conforms to the
            traffic decks. It will neither soften in heat nor embrittle in   substrate requirements as stated in the General Guidelines.
            the cold. Installed and maintained properly, the Poly-I-Gard    Prime all joints, cracks, flashings with approved primers as
                                                              ™
            295/295OF Vehicular Traffic Deck System will ensure years of   specified below in Phase 2. Apply PC-260 over all joints, cracks,
            service. Make sure to use the correct grade of product which   and flashing. Bridge joints, cracks, and flashings with 4” (10.2


        POLYCOAT PRODUCTS TEL 562.802.8834  |  FAX 562.921.7363                                           Section 3.3
        wpsales@polycoatusa.com  |  www.polycoatusa.com
