TECHNICAL DATA SHEET  |  Section 7.4
                                                                                ®
                                                                POLYGLAZE  400FR/400FR-C/400FR-SC
                                                                          Fire Rated, Aliphatic Polyurethane Topcoat





            Product Description
            Polyglaze® 400FR/400FR-C/400FR-SC is an aliphatic, two   Technical Data (Based on Draw Down Film)
            component, liquid applied, moisture cured, polyurethane
            coating.  Polycoat Products manufactures products in different       Polyglaze    Polyglaze     Polyglaze
            VOC’s ranging from 100 to 340 gms/liter to comply with VOC            400FR        400FR-C      400FR-SC
            requirements in various regions. Make sure to use the right          (340 VOC)    (250 VOC)     (100 VOC)
            grade of product which complies with VOC regulations/
            requirements applicable as per federal, state, statutory,   Coverage   1 gal/100 sqft  1 gal/100 sqft  1 gal/100 sqft
            counties, cities and local bodies at the place of installation.  Rate  0.41 l/sqm   0.41 l/sqm   0.41 l/sqm

             Features
                                                                   Dry Film       11 ± 2 mils  11 ± 2 mils   13 ± 2 mils
              •  Durable                                           Thickness       279 ± 50      279 ± 50     330 ± 50
                                                                   per Coat         microns      microns      microns
              •  Fire Retardant
              •  UV Resistant for Gloss Retention                  Hardness,   95 ± 5 Shore A  95 ± 5 Shore A  95 ± 5 Shore A
                                                                   ASTM D2240
             Typical Uses
               •  Concrete                                         Specific        1.36 ± 0.1   1.42 ± 0.1    1.49 ± 0.1
                                                                   Gravity
               •  Heavy Pedestrian Traffic
               •  Plywood                                          Total Solids     79 ± 2%      79 ± 2%       82 ± 2%
                                                                   by Weight,
               •  Vehicular Traffic                                ASTM D2369

             Packaging                                             Total Solids     68 ± 2%      71 ± 2%       77 ± 2%
                                                                   by Volume,
              1-Gallon        1 gallon (3.78 liters) can           ASTM D2697

              5-Gallon        5 gallon (18.9 liters) pail          Viscosity at   2400 ± 500 cps  2700 ± 500 cps  3500 ± 500 cps
                                                                   75°F (24°C)
              55-Gallon       55 gallon drum, net fill 50 gallons (189
                              liters)                              Volatile       2.33 lb/gal   1.67 lb/gal  0.71 lb/gal
                                                                   Organic      280 gm/liters  200 gm/liters  85 gm/liters
                                                                   Compounds
            Colors
            For Polyglaze® 400FR (340 VOC): Tan                  Step 1: Mix the Polyglaze® 400FR/400FR-C/400FR-SC Liquid
            For Polyglaze® 400FR-C (250 VOC): Tan, Dolphin Grey, and   using a mechanical mixer at slow speed until a homogeneous
            Tint-White. Tint-White with color packs are available in Stone   mixture and color is attained. Use caution not to whip air
            Grey, Battleship Grey, Indian Sand, and Ash Brown.   into the material as this may result in pinhole blisters and/
                                                                 or shortened pot life. Do not mix in an up and down motion.
            For Polyglaze® 400FR-SC (100 VOC): Tan, Dolphin Grey, and
            Tint-White. Tint-White with color packs are available in Stone   Step 2: Remove plastic bag of  Polyglaze® 400FR/400FR-
            Grey, Dolphin Grey, Battleship Grey, Tan, Indian Sand and   C/400FR-SC Side-A Powder from the 6 gallon (22.68 liter)
            Ash Brown.                                           pail and set aside. Fill this empty container half full with the
                                                                 pre-mixed Polyglaze® 400FR/400FR-C/400FR-SC Side-B Liquid.
            Custom colors are also available. Minimum order of 250   Slowly add Polyglaze® 400FR/400FR-C/400FR-SC Side-A
            gallons (945 liters). See color chart for special provisions.   Powder, mixing with mechanical mixer.
            Contact Polycoat Products for more information. For pre-
            tinted standard color other than stock color, a minimum of   Ensure that all powder is transferred from the bag to the
            150 gallons (567 liters) is required.                container. Continue mixing until no lumps are present, again
                                                                 being careful not to entrap air in the mixture.
            Coverage
            The approximate coverage is 1 gallon/100 sqft (0.41 l/sqm).   Step 3: When Polyglaze® 400FR/400FR-C/400FR-SC Side-A
            Coverage rate will depend on surface roughness and porosity.  Powder has been thoroughly blended into Polyglaze®
                                                                 400FR/400FR-C/400FR-SC Side-B Liquid add the rest of
                                                                 Polyglaze® 400FR/400FR-C/400FR-SC Side-B Liquid. Mix with
            Mixing                                               mechanical mixer until uniform mixture is attained. Mixed
            The volume mixing ratio is 1 part Polyglaze® 400FR/400FR-  material must be used within 2-4 hours of mixing the two
            C/400FR-SC Side-A Powder to 5 parts of Polyglaze®    components.
            400FR/400FR-C/400FR-SC Side-B Liquid.
