TECHNICAL DATA SHEET I SECTION 3.1
                                                                                                            ®
                                                                                             POLYEURO  7502
                                                                                          Two Component, Aliphatic,
                                                                                         Polyurea Protective Coating



            Product Description                                   Technical Data
            Polyeuro  7502 is a fast setting, rapid curing, 100% solids,
                   ®
            flexible, aliphatic, two component, spray polyurea with   Mix Ratio by Volume                     1A : 1B
            excellent color retention. It can be applied to suitably   Pot Life @150-160ºF (65.5-71ºC), 50% R.H.  10-20 seconds
            prepared interior or exterior concrete and metal surfaces. It
            has extremely fast gel time making it suitable for applications   Tack Free Time (thickness & substrate   60-180 seconds
            down to -20°F (-28.89°C). It may be applied in single or multiple   temperature dependent)
            applications without appreciable sagging and is relatively   Recoat Time                        0-6 hours
            insensitive to moisture and temperature allowing application   Viscosity at 150-160°F (65.5-71°C)
            in most temperatures. Polyeuro  7502 offers a tack free time   Side-A                         120 ± 20 cps
                                       ®
            of less than two minutes and exhibits 300% elongation upon   Side-B                            40 ± 20 cps
            curing with 50 Shore D hardness.                      Density(Side-A & Side-B Combined)        8.50 lbs/gal
             Features                                             Flash Point                           > 200°F (93.3°C)
              •  Coats Carbon or Mild Steel Metals Without Primer  Hardness, ASTM D2240                  50 ± 5 Shore D
              •  Elastomeric                                      Tensile Strength, ASTM D412*           3300 ± 200 psi
              •  Excellent Thermal Stability                                                            22.7 ± 1.38 MPa
              •  Good Chemical Resistance                         Elongation, ASTM D412*                    300 ± 50%
              •  Installed With or Without Reinforcement in Transitional   Tear Strength, ASTM D624*       400 ± 50 pli
               Areas                                                                                    70.1 ± 8.77 kNm
              •  Low  Temperature Flexibility                     Service Temperature - Dry              -40°F to 250°F
              •  Meets USDA Criteria                                                                     -40°C to 121°C
              •  Odorless                                         Service Temperature - Wet               40°F to 120°F
              •  Seamless                                                                              4.44°C to 48.89°C
              •  Zero VOC (100% Solids)                           Volatile Organic Compounds, (Side-A & B    0 lbs/gal
                                                                  combined) ASTM D2369-81                   0 gm/liter
             Typical Uses
                                                                  Recommended Applied Thickness              > 2 mm
              •  Architectural Finishes
              •  Cold-Storage Facilities                          Return to Service: Foot Traffic          2 - 4 hours
              •  Fertilizer Plants                                Return to Service: Full Service          > 24 hours
              •  Food-Processing Plants                           Taber Abrasion Resistance, ASTM D4060 (CS17   33mg loss
              •  Flooring and Parking Decks                       wheel, 1000 cycles, 1 kg load) (maximum)
              •  Industrial and Manufacturing Facilities          Water Absorption, ASTM D471 (maximum 74°F   < 2.0%
              •  Marine Exposure or Submersed Applications        or 23°C, 24 hours)
              •  Mining Operations                                Pull-Off Strength (minimum), ASTM D4541:   Excellent
                                                                  Inter-Coat Adhesion (within recoat time)
              •  Paper and Pulp Mills
              •  Power Plants                                     Concrete (Shot blasted and Primed), substrate   >500 psi (3.4MPa)
                                                                  failure occurred
              •  Refineries                                       Steel (90 μm blast profile)         >900 psi (6.2 MPa)
              •  Secondary Containment
              •  Structural Steel Corrosion Protection            Lineal Shrinkage                            1 - 2%
              •  Tank Coatings External                           Resistance to Weathering, ASTM G-23  No cracking or
                                                                                                     blistering. Color
              •  Walkways and Balconies                           (Type QUV Weatherometer-3000 hrs exposure)  change, gloss reduction
              •  Warehouse Floors                                                                    & chalking are noted.
             Packaging                                            *These physical properties from sample sprayed with Graco EXP2 @ 2000 psi minimum, with
                                                                  Fusion Gun AR4242 @ 150-160°F (65°C to 71°C). Different machine and parameter will change
                                                                  these properties. User should perform their own independent testing as properties are approximate.
              10-gallon kit   5 gallons (18.9 liters) Side-A and 5
                              gallons (18.9 liters) Side-B
                                                                 Color
              100-gallons kit  50 gallons (189 liters) Side-A and 50   Clear/Neutral. Custom colors are available upon request.
                              gallons (189 liters) Side-B
                                                                 Color Packs, when used, must be added to Side-B.








        POLYCOAT PRODUCTS TEL 562.802.8834  |  FAX 562.921.7363                                           Section 3.1
        info@polycoatusa.com  |  www.polycoatusa.com
