GUIDE SPECIFICATIONS |  Section 2.6
                                                                                      POLYDECK  165/165SC
                                                                                                    ®







                                                                   Technical Data

                                                                                                   ®
                                                                   Pedestrian Traffic Deck   Polydeck  165
                                                                   Coating System            70 Dry Mils (1778 microns)
                                                                                             Polydeck  165SC
                                                                                                   ®
                                                                                             72 Dry Mils (1828 microns)
                                                                   Primer                    Polyprime  2180SC
                                                                                                    ®
                                                                                                    ®
                                                                                             Polyprime  EBF-LV
                                                                   Basecoat                  PC-550SC

                                                                                                    ®
                                                                   Topcoat                   Polyglaze  100/100C/100SC
                                                                                                    ®
                                                                                             Polyglaze  AL-50/AL-50SC
                                                                   Packaging
              Concrete Substrate
              (properly prepared substrate)
                                                                   Polyprime  2180SC or      2-gallon kit: One 1 gallon
                                                                            ®
                                                                   Polyprime  EBF-LV         (3.78 liters) can of Side-A
                                                                            ®
                                                                                             and One 1 gallon (3.78 liters)
                                                                                             can of Side-B
                                                                                             or
                                                                                             10-gallon kit: One 5 gallon
                                                                                             (18.9 liters) pail of Side-A
                                                                                             and One 5 gallon (18.9 liters)
                                                                                             pail of Side-B

                                                                   PC-550SC                  1 gallon (3.78 liters) cans or
                                                                                             5 gallon (18.9 liters) pail
                                                                                             (With Vial of Catalyst)

                                                                   Polyglaze  100/100SC or   1 gallon (3.78 liters) cans or
                                                                           ®
                                                                   AL-50/AL-50SC             5 gallon (18.9 liters) pail


              Plywood Substrate
              (properly prepared substrate)

             Features                 Typical Uses               Description
                                                                 The Polydeck  165SC Pedestrian Traffic Deck System is a
                                                                             ®
              •  Applied at Any Thickness  •  Balconies          liquid applied, polyurethane waterproofing deck system. The
              •  Chemical Resistance    •  Over Occupied Space   system utilizes an epoxy primer, one coat of a fast setting water
              •  Elastomeric            •  Patios                catalyzed polyurethane basecoat with a rubber aggregate
              •  Fast Curing            •  Roof Decks            that can be applied at any thickness, and one or two coats
              •  Meets CA VOC & AQMD    •  Sun Decks             of an aliphatic polyurethane topcoat. The Polydeck  165SC
                                                                                                             ®
                Requirements            •  Walkways              decking system is designed to expand and contract with
              •  Non-Gassing                                     normal structural movements. The Polydeck  165SC decking
                                                                                                      ®
              •  Recoatable                                      system can be applied to protect surfaces against spalling,
              •  Seamless                                        freeze/thaw damage, and chemicals commonly encountered
              •  Waterproof
                                                                 on these surfaces. Polydeck  165SC is resistant to weathering.
                                                                                        ®
                                                                 It will not soften in heat nor embrittle in cold. The system is
                                                                 designed for use in a wide range of applications. Installed and
