GUIDE SPECIFICATIONS  |  Section 3.6
                                                                                         POLY-I-GARD  575FR
                                                                                                          ™
                                                                                      (FIRE RATED, CLASS A)





                                                                   Technical Data

                                                                   56 Dry Mil (1422 microns)
                                                                   Vehicular Traffic Deck Coating System


                                                                   Primer             Polyprime  21
                                                                                              ®
                                                                                      Polyprime  2180SC
                                                                                              ®
                                                                                      Polyprime  EBF-LV
                                                                                              ®
                                                                   Base Coat          PC-260
                                                                   Topcoat            Poly-I-Gard  295
                                                                                               ™


                                                                   Packaging

                                                                   Polyprime  21             3-gallon kit: One 3.5 gallon
                                                                            ®
              Concrete Substrate (properly prepared substrate)                               pail, net fill 2 gallons (7.57
                                                                                             liters) of Side-A and One
                                                                                             1 gallon (3.78 liters) can of
             Features                 Typical Usage                                          Side-B or
                                                                                             5-gallon kit: Two 5 gallon
              •  Applied at Any Thickness  •  Balconies                                      (18.9 liters) pails of Side-A
              •  Chemical Resistant     •  Concrete Roof and Decks                           and One 5 gallon (18.9 liters)
              •  Elastomeric            •  Helicopter Pads                                   pail of Side-B
              •  Good Thermal Stability  •  Over Occupied Spaces
              •  Meets USDA Criteria    •  Vehicular Decks         Polyprime  2180SC or      2-gallon kit: One 1 gallon
                                                                            ®
              •  Non-Gassing            •  Walkways/Stairs         Polyprime  EBF-LV         (3.78 liters) can of Side-A
                                                                            ®
              •  Recoatable                                                                  and One 1 gallon (3.78 liters)
                                                                                             can of Side-B or
              •  Seamless                                                                    10-gallon kit: One 5 gallon
              •  Very Rapid Setting                                                          (18.9 liters) pail of Side-A
              •  Waterproof                                                                  and One 5 gallon (18.9 liters)
                                                                                             pail of Side-B

                                                                   PC-260                    1 gallon kit: One 1 gallon
             Primers, base and topcoats have a shelf life of 1 year from date                can, net fill 0.8 gallons (3
             of manufacture in original, factory-sealed containers when stored               liters) of Side-A and One
             indoors at a temperature between 60-95˚F (15-35˚C).                             quart can, net fill 0.2 gallons
                                                                                             (0.78 liters) of Side-B or
            Description                                                                      5 gallon kit: One 5 gallon
                                                                                             pail, net fill 4 gallons (15.12
            The Poly-I-Gard  575FR (Fire Rated, Class A) Vehicular Traffic                   liters) of Side-A and One
                         ™
            Deck System is a very fast setting, rapid curing, 100% solids,                   1 gallon (3.78 liters) can of
            polyurethane/polyurea, liquid applied, chemically-cured                          Side-B
            waterproofing coating system. The system utilizes a two-
                                                                             ™
            component epoxy primer, a two-component, non-gassing,   Poly-I-Gard  295         4.4-gallon kit: One 5-gallon
            thermal stable elastomeric basecoat, and a two-component,                        pail, net fill 4-gallons (15.12
                                                                                             liters) of Side-A, and one 1/2
            solvent free, hybrid aliphatic polyurea topcoat.                                 gallon (1.89 liters), net fill
            The Poly-I-Gard  575FR Vehicular Traffic Deck System is a                        0.4 gallon(1.512 liters) jar of
                          ™
            user friendly, low odor coating system that is specifically                      Side-B
            designed to be tough and durable enough to withstand light
            to heavy vehicular traffic. It is a high elongation, elastomeric
