TECHNICAL DATA SHEET | Section 11.3
SUPER SEAL TAPE
Pressure Sensitive Tape for Metals, Flashings, Plywood
and Concrete Surfaces

Product Description Features
Super Seal Tape is a 9 mil thick, laminated, spun-bonded
polyester substrate reinforced with hybrid polyester fibers. • Adhesion to Most Common Construction Metals
These fibers have been specifically created to provide high • Coating Ready
modulus of strength on initial impact. The adhesive is a highly • Compatible with Most Coatings
aggressive acrylic system that delivers high tack and high
shear strength. This product has an excellent adhesion to metal • Fast Tack Set
or wood. The adhesive has excellent cold temperature and • Field or Shop Applied to Substrates
condensation resistance with an extremely wide application • Labor Saving
gradient and a built-in ultra violet stabilizer system. • Ultra-Violet Stable
• User Friendly
Packaging • Waterproof

,
,
,
,
Widths: 4” 8” 12” 16” 24” and 48” rolls (10.14 cm,
20.14cm, 30.48 cm, 60.96 cm, 121.29 cm) Typical Uses
Lengths: 180’ (55 m) • Balcony and Breezeway Waterproofing
• Balcony Flashing Tape
Color • Basements
White
• Coatings Over Metal
• Foundation Walls
• Green Roof Waterproofing
• Roof Repair
• Roofing Joints

Technical Data

Base Material Spun-Bonded Polyolefin
Fibers Polyester Hybrid
Thickness 9 Mils (2.286 microns)
Tensile 1,000 lbs per inch
Elasticity 6%
Memory 98%
Temperature Resistance 10 to 250°F
-4 to 121°C
Minimum Application Temperature -23°C (-9.4ºF)
Release Liner 90 GSM PE Liner
Adhesion to Galvanized Steel 28.5 lbs p/Lft @ RT
20 min Dwell
Adhesion to Copper 24.75 lbs p/Lft @ RT
20 min Dwell
Adhesion to Steel 32.25 lbs p/Lft @ RT
20 min Dwell
Adhesion to Aluminum 38.66 lbs p/Lft @ RT
20 min Dwell
