TECHNICAL DATA SHEET | Section 11.2
STRAIGHT JACKET TAPE
Fiberglass Mesh Tape

Product Description Features
Straight Jacket Tape is a fiberglass mesh tape. Straight Jacket
Tape is used in the Fire Rated Polydeck Decking Systems Excellent Reinforcement of Stress Areas
®
Color Typical Uses
Off-White
Straight Jacket Tape is used in the Fire Rated Polydeck
®
decking systems.
Provides excellent reinforcement for:
• Concrete
• Cracks
• Flashings
• Joints
• Other High Stress Areas
• Plywood
• Seams
Packaging

Single Rolls - 4” x 150’ (10.16 cm x 45.7 m)
Sold Individually or in Cases of 18 Rolls

Technical Data

Coverage per roll, length, observed 150 ft (3.81 m)
45.7 meters

Thickness, observed 0.007”
0.18 mm

Average weight, observed 1.9 oz/sqy
64.4 gm/sqm

Tensile Strength, ASTM D1668 ll,
Warp 85 psi (0.6 Mpa)
Fill 85 psi (0.6 Mpa)

Thread, ASTM D1668 ll
Warp 20
Fill 20

Yarn, ASTM D1668 ll
Warp 150-1/0
Fill 150-1/0

POLYCOAT PRODUCTS TEL 562.802.8834 | FAX 562.921.7363 Section 11.2
wpsales@polycoatusa.com | www.polycoatusa.com
