GUIDE SPECIFICATIONS  |  Section 3.2
                                                                                            POLY-I-GARD  246
                                                                                                             ™






            Concrete must exhibit 3000 psi minimum strength. Concrete   Equipment should be cleaned with a urethane grade
            surfaces to be coated must be trowel finished in compliance with   environmentally safe solvent, as permitted under local
            the American Concrete Institute (except that hand troweling   regulations, immediately after use. Uncured materials
            is not required), followed by a fine-haired brooming, left free   are sensitive to heat and moisture. The substrate must be
            of loose particles, and shall be without ridges, projections,   structurally sound and sloped for proper drainage. Polycoat
            voids and concrete droppings that would be mechanically   Products assumes no liability for substrate defects. Field visits
            detrimental to coating application or function.      by Polycoat Products personnel are for the purpose of making
                                                                 technical recommendations only and are not to supervise or
            New concrete must be cured for 28 days (see General   provide quality control on the job site.
            Guidelines). Polycoat Products coating systems should not
            be subjected to rising water tables or hydrostatic pressure on   Warning
            slab-on-grade decks. The only acceptable grade of plywood   The products in this system contain Isocyanates, Solvents, Epoxy Resin,
            is APA rated exterior grade or better. The appearance and   and Curatives.
            physical characteristics of the plywood and grade should be
            considered. Plywood should be new or cleaned and sanded
            (see General Guidelines). The coating should be applied at
            least 5°F (3°C) above the dew point.
            Coverage rates recommended are based on lab conditions,
            applied at 75°F (24°C) ambient temperature and are intended
            to be minimum coverage rates on clean, smooth plywood, and
            are exclusive of additional amounts needed to fill potholes,
            spalling, scaling, rough and irregular surfaces.  Porosity and
            roughness of the substrate, aggregate size, and product
            temperature will affect coverage rates. Material mil thickness
            rates are calculated on theoretical coverage for a smooth
            substrate and do not account for the actual texture or substrate
            conditions in the field or at the time of application.  Sample
            mockups on the projects are recommended to determine the
            exact coverage rates necessary to waterproof the deck to
            acceptable standards.












            Limited Warranty: Please read all information in the General Guidelines, Technical Data Sheets, Guide Specifications and Safety Data Sheets (SDS) before applying material. These
            products are for professional use only and preferably applied by professionals who have prior experience with the Polycoat Products materials or have undergone training in application
            of Polycoat Products materials. Published technical data and instructions are subject to change without notice. Contact your local Polycoat Products representative or visit our website for
            current technical data, instructions, and project specific recommendations.
            Polycoat Products warrants its products to be free of manufacturing defects and that they will meet Polycoat Products’ current published physical properties. Seller’s and manufacturer’s
            sole responsibility shall be to replace that portion of the product which proves to be defective. There are no other warranties by Polycoat Products of any nature whatsoever expressed or
            implied, including any warranty of merchantability or fitness for a particular purpose in connection with this product. Polycoat Products shall not be liable for damages of any sort, including
            remote or consequential damages resulting from any claimed breach of any warranty whether expressed or implied. Polycoat Products shall not be responsible for use of this product in a
            manner to infringe on any patent held by others. In addition, no warranty or guarantee is being issued with respect to appearance, color, fading, chalking, staining, shrinkage, peeling, normal
            wear and tear or improper application by the applicator. Damage caused by abuse, neglect and lack of proper maintenance, acts of nature and/or physical movement of the substrate or
            structural defects are also excluded from the limited warranty. Polycoat Products reserves the right to conduct performance tests on any material claimed to be defective prior to any repairs
            by owner, general contractor, or applicator.
            Disclaimer: All guidelines, recommendations, statements, and technical data contained herein are based on information and tests we believe to be reliable and correct, but accuracy and
            completeness of said tests are not guaranteed and are not to be construed as a warranty, either expressed or implied. It is the user’s responsibility to satisfy himself, by his own information and
            test, to determine suitability of the product for his own intended use, application and job situation and user assumes all risk and liability resulting from his use of the product. We do not suggest
            or guarantee that any hazard listed herein are the only ones which may exist. Neither seller nor manufacturer shall be liable to the buyer or any third person for any injury, loss or damage directly
            or indirectly resulting from use of, or inability to use, the product. Recommendations or statements, whether in writing or oral, other than those contained herein shall not be binding upon the
            manufacturer, unless in writing and signed by a corporate officer of the manufacturer. Technical and application information is provided for the purpose of establishing a general profile of the
            material and proper application procedures. Test performance results were obtained in a controlled environment and Polycoat Products makes no claim that these tests or any other tests
            accurately represent all environments. Polycoat Products is not responsible for typographical errors. © 2020 Polycoat Products. All rights reserved. Revision 20200910.DM

        POLYCOAT PRODUCTS TEL 562.802.8834  |  FAX 562.921.7363                                           Section 3.2
