GUIDE SPECIFICATIONS  |  Section 2.4
                                                                                      POLYDECK  160/160SC
                                                                                                    ®







                                                                   Technical Data

                                                                   Pedestrian Traffic Deck   60 Dry Mils (1524 microns)
                                                                   Coating System            (Sand Aggregate)
                                                                                             72 Dry Mils (1828 microns)
                                                                                             (Rubber Aggregate)

                                                                   Primer                    Polyprime  2180SC
                                                                                                    ®
                                                                                             Polyprime  EBF-LV
                                                                                                    ®
                                                                   Basecoat                  PC-260

                                                                   Topcoat                   Polyglaze  100/100C/100SC
                                                                                                    ®
                                                                                             Polyglaze  AR/AR-OF
                                                                                                    ®
                                                                                             Polyglaze  AL-50/AL-50SC
                                                                                                    ®

              Concrete Substrate (properly prepared substrate)     Packaging


                                                                   Polyprime  2180SC or      2-gallon kit: One 1 gallon
                                                                            ®
                                                                   Polyprime  EBF-LV         (3.78 liters) can of Side-A
                                                                            ®
                                                                                             and One 1 gallon (3.78 liters)
                                                                                             can of Side-B
                                                                                             or
                                                                                             10-gallon kit: One 5 gallon
                                                                                             (18.9 liters) pail of Side-A
                                                                                             and One 5 gallon (18.9 liters)
                                                                                             pail of Side-B

                                                                   PC-260                    1-gallon kit: One 1 gallon
                                                                                             can, net fill 0.8 gallons (3
                                                                                             liters) of Side-A and One
                                                                                             quart can, net fill 0.2 gallons
                                                                                             0.78 liters) of Side-B or
                                                                                             5-gallon kit: One 5 gallon
                                                                                             pail, net fill 4 gallons (15.12
                                                                                             liters) of Side-A and One
              Plywood Substrate (properly prepared substrate)                                1 gallon (3.78 liters) can of
                                                                                             Side-B
             Features                 Typical Uses
                                                                   Polyglaze  AR/AR-OF or    1 gallon (3.78 liters) cans or
                                                                           ®
              •  Applied at Any Thickness  •  Balconies            100/100SC or              5 gallon (18.9 liters) pail
              •  Chemical Resistance    •  Patios                  AL-50/AL-50SC
              •  Elastomeric            •  Roof Decks
              •  Fast Curing            •  Sun Decks
              •  Good Thermal Stability  •  Walkways             Description
              •  Non-Gassing                                     The Polydeck  160/160SC Pedestrian Traffic Deck System is a
                                                                            ®
              •  Recoatable                                      liquid applied, high performance, polyurethane waterproofing
              •  Seamless                                        system. The system utilizes an epoxy primer, one coat of a
              •  Waterproof                                      fast setting, chemically cured, two component, polyurethane
            Primers, base and topcoats have a shelf life of 1 year from date of manufacture   elastomeric basecoat with a rubber aggregate that can be
            in original, factory-sealed containers when stored indoors at a temperature   applied at any thickness on concrete, plywood and metal
            between 60-95˚F (15-35˚C).
